SS_SWUC_HA

SS_SWUC_HA （Hard steel shank with coolant hole）

  • Type1
  • Boring Bars
  • High-Performance steel shank having excellent durability against damage by chips
  • Internal coolant support with coolant holes enables stable coolant even during deep hole machining

※Actual products and images (representative examples) may differ. Please check the dimensions column in the table below for details.

2D CAD data(DXF) 3D CAD data(STP)Detailed 3D CAD data(STP,STL)Simplified Product List(XLSX)
EDP Order Number Type Stock UST Hand KAPR DMIN DCONMS LF LDRED WF H GAMF GAMP CSP CICT Applicable_Inserts
23706651 H12-10SWUCR04-080-C Type 1 M Right Hand 93 ° 12 10 80 20 6 9.7 12 ° 0 ◯ 1 WCM〇0402〇〇,WCGT0402〇〇
23706675 H12-10SWUCL04-080-C Type 1 M Left Hand 93 ° 12 10 80 20 6 9.7 12 ° 0 ◯ 1 WCM〇0402〇〇,WCGT0402〇〇
