SS_SCLP_E

SS_SCLP_E （Carbide shank with coolant hole）

  • Type1
  • Boring Bars
  • Carbide shank with coolant hole

※Actual products and images (representative examples) may differ. Please check the dimensions column in the table below for details.

2D Model(DXF) 3D Detail Model(STP,STL) 3D Light Model(STP,STL) Product List(XLSX)
EDP Order Number Type Stock UST Hand KAPR DMIN DCONMS LF LDRED WF H GAMF GAMP CSP CICT Applicable_Inserts
22979773 C12-10SCLPR08-140-C Type 1 M Right Hand 95 ° 12 10 140 18 6 9 5 ° 5 ° ◯ 1 CPM〇0802〇〇,CPG〇0802〇〇
22980694 C14-12SCLPR08-140-C Type 1 M Right Hand 95 ° 14 12 140 23 7 11 4 ° 5 ° ◯ 1 CPM〇0802〇〇,CPG〇0802〇〇
22980816 C16-12SCLPR09-140-C Type 1 M Right Hand 95 ° 16 12 140 23 8 11 4 ° 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
22979636 C18-16SCLPR09-180-C Type 1 M Right Hand 95 ° 18 16 180 28 9 15 3.5 ° 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
22980960 C22-20SCLPR09-180-C Type 1 M Right Hand 95 ° 22 20 180 32 11 19 2 ° 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
23156937 C27-25SCLPR09-180-C Type 1 M Right Hand 95 ° 27 25 180 38 13.5 24 0 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
23156968 C30-25SCLPR09-180-C Type 1 M Right Hand 95 ° 30 25 180 38 15 24 0 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
22979742 C12-10SCLPL08-140-C Type 1 M Left Hand 95 ° 12 10 140 18 6 9 5 ° 5 ° ◯ 1 CPM〇0802〇〇,CPG〇0802〇〇
22980687 C14-12SCLPL08-140-C Type 1 M Left Hand 95 ° 14 12 140 23 7 11 4 ° 5 ° ◯ 1 CPM〇0802〇〇,CPG〇0802〇〇
22980793 C16-12SCLPL09-140-C Type 1 M Left Hand 95 ° 16 12 140 23 8 11 4 ° 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
22979674 C18-16SCLPL09-180-C Type 1 M Left Hand 95 ° 18 16 180 28 9 15 3.5 ° 5 ° ◯ 1 CPM〇0903〇〇,CPG〇0903〇〇
