DPCL

DPCL

  • Type1
  • Boring Bars
  • Economical negative insert.
  • Lever lock type
  • Exchangeable head type.

※Actual products and images (representative examples) may differ. Please check the dimensions column in the table below for details.

2D CAD data(DXF) 3D CAD data(STP)Detailed 3D CAD data(STP,STL)Simplified Product List(XLSX)
EDP Order Number Type Stock UST Hand KAPR DMIN DCONMS LF WF GAMF GAMP
112015 DPCL132R Type 1 M Right Hand 95 ° 40 32 40 20 12 ° -6 °
10055939 DPCL140R Type 1 M Right Hand 95 ° 50 40 50 25 10 ° -6 °
