SS_SVUC/B_A

SS_SVUC_B_A （Steel shank with coolant hole）

S16-12SVUCR08-090-C

  • Boring Bars
  • Steel shank type
  • Internal coolant support with coolant holes enables stable coolant even during deep hole machining

※Actual products and images (representative examples) may differ. Please check the dimensions column in the table below for details.

EDP No：23653016

2D CAD data(DXF) 3D CAD data(STP)Detailed 3D CAD data(STP,STL)Simplified

Product Details
Stock
Inventory maintained.
UST
M
Hand
Right Hand
KAPR
93°
DMIN
16
DCONMS
12
LF
90
LDRED
25.5
WF
11.5
WF2
5.6
H
11
GAMF
8°
GAMP
0
CSP
◯
CICT
1
Applicable_Inserts
VCGT0802〇〇,VCMT0802〇〇,VCET0802〇〇
