Turning Tools

Small Tools Inserts

Insert for BTVH Holder

P M K S

BTVT5375V5R-B

※Actual products and images (representative examples) may differ. Please check the dimensions column in the table below for details.

EDP No：264583

Product Details
Stock
Inventory maintained.
Tool_Material
PVD Carbide
Grade
VP15TF
HAND
Right Hand
CTX
0.5
LE
7.5
IC
6.35
S
3.18
RE
0.05
AN
7°
CBMD
B

Stock:

:Inventory maintained.

:Non stock, produced to order only.

:Inventory maintained. To be replaced by new products.

:Inventory maintained in Japan.
